Eddy Current Testing Equipment is a reliable and efficient tool for eddy current inspection, designed for easy and accurate testing. This eddy current testing equipment features an alarm output with triode OC gate, adjustable gain from 0 to 90 dB in 0.5 dB steps, and up to 8 levels of drive voltage. This eddy current equipment also offers tube sheet mapping, which draws according to the real tube layout, and marks testing results in different colors. This eddy current inspection equipment is perfect for precision testing, providing quality assurance for users. The eddy current test equipment is ideal for a variety of industries, ensuring accurate and reliable results.
| Battery | Built-in Lithium Battery (14.8V,5.7AH),long Working Time Of 10 Hours After One Time Charge |
|---|---|
| Machine size | 290mm X 210mm X 42.5mm |
| Tube Sheet Mapping | Tube Sheet Mapping Draws According To Real Tube Layout,and Testing Result Is Marked In Different Colors |
| Standards | ASTM,JB/T4730.6-2005,DLT 883-2004 Etc. |
| Phase | 0-359 In 0.1steps |
| Calibration | Calibration On Known Flaws And Automatic Generation Of Calibration Curve. Calibration Data Can Be Saved And Simply Called Up When Needed |
| Operating Temperature | -20℃ To 55℃ |
| Frequency | 2 Frequencies Per Channel With 64Hz-5MHz For ECT,5Hz-5KHz For RFT |
| Channel | 2 Channels |
| Filter | High Pass:0-500Hz Low Pass:10-10000 Hz Digital1-100 |
HUATEC HEF-C35RFT Eddy Current Testing Equipment is made in China and has been certified with CE. It has minimum order quantity of 1pc and is packaged in standard carton. Delivery time is 5 days and payment terms are T/T L/C. The monthly supply ability of this product is 100pcs. It has a fast digital/analog electronic balance and gain ratio (Y/: 0.1-10. It also has 2 channels and a mixing unit to suppress noise signal at a constant frequency.
This eddy current test equipment is widely used for non-destructive testing (NDT) during the manufacturing process. It is used to detect flaws such as cracks, voids, inclusions, porosity, heat treatment, and other defects in metal products. It is also used to check the integrity of welds and to measure material thickness. The eddy current testing machine is ideal for inspecting the surface integrity of metals and metal alloys quickly and accurately.
HUATEC’s Eddy Current Testing Equipment is reliable, accurate, and easy to operate. It can be used in a variety of industries such as aerospace, automotive, medical, and electronics. It is an essential tool for quality assurance and product reliability.
HUATEC HEF-C35RFT is a portable eddy current flaw detector for eddy current test equipment and eddy current testing equipment. It has high sensitivity and accuracy, and can be used to detect flaws on the surface of the inspected object. It has 2 channels, and the mixing unit can suppress noise signals at a constant frequency. The real-time strip chart, impedance plane, and tube sheet display can be used to display the results in different formats. The machine weight is 2.0kg.
We provide comprehensive technical support and services for Eddy Current Testing Equipment.
Packaging and Shipping for the Eddy Current Testing Equipment:
We will package the Eddy Current Testing Equipment in standard shipping boxes. Each box will be securely sealed and labeled to ensure that the product arrives to you without any damage. Our shipping department will work with you to schedule the delivery of the product. We offer several different shipping options to best suit your needs.
