LCD Display Pencil Hardness Tester Digital Built-in Printer Bench Type

LCD Display Pencil Hardness Tester Digital Built-in Printer Bench Type
LCD Display Pencil Hardness Tester Digital Built-in Printer Bench Type LCD Display Pencil Hardness Tester Digital Built-in Printer Bench Type

Large Image :  LCD Display Pencil Hardness Tester Digital Built-in Printer Bench Type Get Best Price

Product Details:

Place of Origin: Beijing
Brand Name: HUATEC
Certification: ISO, CE, GOST
Model Number: HK-1P

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Packaging Details: Standard export package
Delivery Time: 1-4days
Payment Terms: T/T, Paypal, Western Union
Supply Ability: 500pcs per month
Detailed Product Description
Standard: GB / T 26704-2011 Pencil Test Test Force: 0.245,0.49,0.98,1.96,2.94,4.98
Hardness Test Range (HK): 40-700 Indenter And Lens Converters: Automatic
Size: 405*290*480mm
High Light:

portable hardness testing machine

,

hardness testing equipment

LCD Display Pencil Hardness Tester Digital Built-in Printer







Main Description:

HK-1M Digital pencil hardness tester designed for a variety of pencils pencil hardness testing, performance standards "GB / T 26704-2011 pencil Test"



The hardness tester using a large screen LCD display, user interface using the menu structure, hardness testing HK automatically calculated.



Strictly conformed accordance with GB / T 26704 for data processing Innovative unique fixture convenience sample grinding and hardness measurements.



Switch between the indenter and the objective in the test, the test point automatic positioning accuracy.



Test results can be automatically stored, processed, printed.



  Technical parameters

Product Type

HK-1M

Standards Conformed to

<GB/T 26704-2011 Pencil Testing>

Test force (N)

0.245,0.49,0.98,1.96,2.94,4.98

Minimum test unit

0.062µm

Hardness test range (HK)

40-700

Test force loading

Automatic (loading, dwell, unloading)

Indenter and lens converters

Automatic

Test microscope magnification

100X (for observation) ,

200X (for test)

Test force dwell time

0~60s,Recommended 10s

X-Y Test table

Dimension:100*100mm  Movement:25*25mm

Data Output

LCD readout display, built-in printer

The indenter center-outer wall Distance

95mm

Power supply

AC220V+5%,50-60Hz

Dimensions

405*290*480mm

Weight

25Kg





 Standard Accessories

Part Name

Quantity

Part Name

Quantity

Axle weight

1

Weight

6pcs

Cross test sets

1

Lead holder

1

Small Level

1

10X eyepiece test

1

Screw driver

2pcs

Foot adjustment screw

4pcs

Power cable

1

Spare fuse (2A)

2pcs

Product Manual



1

Product certification

1



LCD Display Pencil Hardness Tester Digital Built-in Printer Bench Type 0





LCD Display Pencil Hardness Tester Digital Built-in Printer Bench Type 1
