HUATEC HDL-430XD professional medical tablet X Ray film processor
Rinse process:
Technical parameters
Film specification: Minimum 5 x 10 cm to 43 cm wide
Running time: 70-140 seconds
Development time: 20-60 seconds
Intake speed: 750~150 millimeter / min
Flush volume: 245 sheets (14 "*17") / hour; 376 sheets (10 "*12") / hour
Tank volume: 12.5 liters
Replenishment: automatic test supplementation of 50-200 ml / m2
Developing temperature: adjustable from 20-40 degrees
Setting temperature: automatic adjustment based on developing temperature
Drying temperature: 20-70 degrees
Water temperature: 5~30 degree
Water consumption: less than 2 liters / minutes in film operation
Power: 220~240V10A 50 or 60Hz
Weight: 95 kilograms (no liquid in the slot)
Volume: (long * width * height) 105*71.5*123 cm
Four. The selection device:
(1) water washing and inflow thermostat;
(2) the temperature supertemperature cooling device of the developer;
(3) water wash water and display device;
(4) the red light control system in the box.
